1KW-12KW Off Grid Pure Sine Wave Inverter 12V/24V/48VDC Solar inverter

DC To AC Off Grid Pure Sine Wave Inverter AC Off Grid Pure Sine Wave Inverter is a real sine wave off grid system hybrid Inverter, convert DC to AC output power to your almost all of your household appliances, power tools, fans, lights, and other electronics without interference.

Email

MP series Inverter is a device for converting a direct current into an alternating current with a sinusoidal waveform. Most often used for the operation of household devices (220V) from a car battery. Inverters of this series have a built-in charging function for car batteries from the city network. Also widely used instead of UPS, with plug-in external batteries. The maximum total capacity of the connected batteries is not limited. This series of inverters has the ability to drive an LCD display up to 15M from the inverter using the RJ-45 ports installed on the inverter and LCD display for remote monitoring of the inverter's readings.

1KW/2KW/3KW/4KW/5KW/6KW/10KW/12KW

Feature:

*Pure sine wave inverter with AVR and Colds start function

*Built-in MPPT controller for option;

*Selectable INV MODE range 100Vac-290Vac or UPS MODE 160Vac-275Vac for home appliances and personal computers

*Selectable up to 8 types battery

*Compatible to mains voltage or generator output

*Auto restart while AC is recovering, Overload and short circuit protections

*Smart battery charger design for optimized battery performance

*Remote control function USB and RS232 communication function

*Selectable solar charging current from 10A to 100A

*Configurable AC/Solar input priority via LCD setting

*Setting of battery shutdown voltage

*Setting of battery voltage from solar priority to AC priority

Specifications:

Application:

Suitable for the PC,router,POS machine communication processor,industrial products which for the enterprises,government,scientific research,traffic,national defense,information and education industries.

Performance Characteristics:

1. Wide range of input voltage

The UPS can offer normal and stable service voltage under its input voltage range. When the input voltage is out of its range the machine will switch to battery mode automatically to keep the output power in order to protect the equipment, such as computers, ensure they will not be damaged by the over high or over low voltage, users can continue the operation of equipment for a while or save the data on computers while the power network is abnormal.

2. Wide range of AVR(Automatic voltage regulation)

In the product's input voltage range and under 3 steps of intelligent AVR function, it can provide a stable output voltage.

3. Automatic self detection when UPS on(LED).

Before the UPS on, red, yellow, blue LED will light up two times by cycle turns, after self detection UPS switch to AC mode/battery mode or working mode.

4. Silence function

In the "battery mode", shortly press the switch to turn off the buzzer. But the battery is about to run out or the load is too heavy, the buzzer sound cannot be muted.

5. Overload protection

In the battery mode, output voltage turn down correspondingly when it is overload, after the capacity of load is lower than the rated power then output voltage will back to rated value, it ensures the UPS will not shut down by abrupt overload which caused by surging current during the computer is working and other equipment is added.

6. Short circuit protection

When the mis-operation caused the load short circuit or computer failure (such as power tube breakdown of switch) cause short circuit, the UPS will shutdown automatically for protection.

7. The low current switch

This UPS adopts low current switch to extend the service life which is longer than conventional battery and high current switch in AC current path.

8. Automatic charging

There are two charging mode, charging time is faster than ordinary charging mode, higher efficiency, and greatly prolonging the service life of the battery.

9. With a bypass output

Independent bypass output socket for external printers or scanners of computer peripherals, with surge protection of the load.
